Operation & Maintenance A70T EPP EvoControl

3 Acetec •Product catalog • Ventilation unit Installation A70T Installation and commissioning must be done by a person with sufficient knowledge for the industry for a good function. The right or left variant is determined by mounting the unit rotated. The unit is mounted against the wall using the enclosed suspension angle. During kitchen installation, the unit and kitchen hood are mounted as separate units, which simplifies the installation. The kitchen hood is connected to the unit with a 125 mm hose (hose not included). Electrical connectors are connected to the underside of the unit. Basic airflow must not be taken via the kitchen hood. Separate exhaust air diffusers are installed in the kitchen. The minimum construction height between the upper edge of the kitchen hood and the upper edge of the unit is 620 mm. This mounting method provides more space above the unit for duct adjustment, flexible mounting and lower weight. Electrical connection The unit is internally pre-connected and equipped with a cord. The plug is connected to a grounded socket 1x230 V, 10 A slow fuse. The control panel is connected to the unit with a flat cable, length 5 m with quick connectors. When the kitchen hood is used, connect the hood's electrical connectors to the underside of the unit. Connectors for lighting and control signals are connected to the unit's connectors. Kitchen hood white 251-A70T 600mm Kitchen hood stainless 251-A70T 600mm Kitchen hood 392-A70T 600mm wall Wall mount is attached to the wall. The unit rotational placement gives the right or left variant Minimum 620 mm Hose (not included)
